We are a perfect destination for you if your search comprises of excellent quality Home UPS. The power solutions UPS available with us are known for their high durability and precision. We offer customized services of Power Inverters as per the needs of our customers and are believed as one of the leading Domestic UPS system manufacturer.

SALIENT FEATURES:
  • Highly Efficient.
  • Fully redundant and configuration design.
  • Excellent quality and high durability.
  • PWM Technology with High Voltage Protection on mains.
  • Ruggedised construction, Excellent quality and high durability.
APPLICATIONS:
  • Homes, Apartments and Villas
  • Offices and Fuel Stations.
  • Hotels & Resorts
  • Shopping Centers
Technical Specification
Technology PWM Technology with High Voltage Protection on mains
Capacity 650VA- 5KVADomestic and Sinewave Power Inverter Available up to 30 KVA (Single and Three Phase)
Input Voltage : 130V to 260V AC (PN) Frequency : 50Hz+/- 3Hz.
Output Voltage: 230VAC (Nominal On Inverter and only Bypass On Mains) Frequency : 50Hz+/- 0.1Hz (on Battery) Regulation : 230V+/- 4% (on Battery).
Wave form Quasi Square Wave / Sine wave.
Power Factor 0.8 Lag to unity.
Display LCD display for all parameters
Efficiency Better than 90%.
Switching Devices Using "MOSFET"/ "IGBT" Devices
Transfer time Less than 10 - 15 m sec / less than 1 sec for Power Inverter
Noise Level Less than 45 dB
With standing Capacity 150% Over Load for 60 sec.
Type of Cooling Natural Air Cooling
Mode of Charging Constant Voltage, Constant Current Charger
Protections Input: Mains Over Voltage / Spikes / Surges.
Battery: Over Charge / Low Voltage.
Output: Over Load / Short Circuit.
Display LCD display for 5 Kva and above
Indications Mains ON / Inverter On / Battery Low / Overload
Alarms Battery Low / Over Load
Battery (Type) External batteries, Tubular / SMF
Backup Provisions 1Hr. to 8 Hours
Battery Voltage 12V to 360V
Recharging Time 10 to 12 Hours
